Ayre AX-5 User Manual

To enter the advanced setup mode, make sure that
the amplifier is in the low-current consumption
state (green LED illuminated on the right-hand
button). Then press and hold the left-hand button
for three seconds. This enters the unit into the basic
setup mode. The display will briefly show
“
SET UP” and then display “XXX 1” where
“XXX” is the name assigned to input 1.
Use the right-hand knob to select which input
(
1 - 6) you wish to configure with advanced options.
Then briefly press the right-hand button to enter
the advanced menu level. The left-hand knob will
select which setting you wish to configure for that
input:
• CN - Custom Name
• GOS - Gain Offset
• PP - Processor Pass-Through
• AL - AyreLink
• RST - Reset
After you have selected the desired choice, press the
right-hand button to enter the selection.
18
XXX 1
SET UP
CN
GOS
PP
AL
RST
