AZ-Delivery DS3231 - Connecting the Module with Raspberry Pi

Connecting the module with Raspberry Pi
Connect the DS3231 RTC module with the Raspberry Pi as shown on the
following connection diagram:
RTC pin
Microcontroller pin
Physical pin Wire color
VCC 3V3 1 Red wire
SDA GPIO2 3
Blue wire
GND GND 6 Black wire
SCL GPIO3 5
Green wire
- 20 -
