AZ 8801 - BUTTON DESCRIPTION; OPERATION

OPERATION
BUTTON DESCRIPTION
Model: 8801
Single Input
Model: 8803
Dual Input
ON/OFF
HOLD
MAX HLD
T1.T2
T1-T2
oo
C/ F
Power ON and Power OFF
oo
Unit selectable C or F
Freeze the current reading
Record Maximum reading
T1 temperature or
T2 temperature or differential
temperature between T1&
T2
Plug thermocouple in the meter as
shown Figure 1 or 2.
Press ON/OFF button to start. Fig. 3
shows the normal display when either
T1 or T2 thermocouple is pluged in.
++
T2T2
T1T1
++
++
#8801
Fig.1
#8803
Fig.2
o
C
Fig.3
