Specifications
Item Specification
Temperature 0 C to 50 C Measuring range
Humidity 0 %RH to 100 %RH (15 C 35 C)
Temperature 4 mA DC to 20 mA DC, 2-wire type (linear to 0 C to 50C)
(Max. allowable load: 500 or lower)
Output signal
Humidity 4 mA DC to 20 mA DC, 2-wire type (linear to 0 %RH to 100 %RH)
(Max. allowable load: 500 or lower)
Temperature 0.3 C (at 15 C to 35 C, 50 %RH)
0.5 C (at 0 C to 50 C, 50 %RH)
Required conditions
24 V DC input power voltage, 250 resistive load, 0.15 m/s wind velocity, and
60 minute warm-up time
Note that the wind velocity other than 0.15 m/s lowers the sensing accuracy.
Model TY7043D at 0.35 m/s wind velocity -0.7 C
Model HTY7043D at 0.35 m/s wind velocity -0.9 C
If using Neosensor under conditions not specified above, ask our salesperson.
Sensing accuracy
Humidity 3 %RH (at 30 %RH to 70 %RH, 25 C)
5 %RH (at 20 %RH to 80 %RH, 15 C to 35 C)
Required conditions
24 V DC input power voltage, 250 resistive load, 0.15 m/s wind velocity, and
60 minute warm-up time
Note that the wind velocity other than 0.15 m/s lowers the sensing accuracy.
Model HY7043D at 0.35 m/s wind velocity +2.4 %RH
Model HTY7043D at 0.35 m/s wind velocity +2.8 %RH
If using Neosensor under conditions not specified above, ask our salesperson.
Temperature 4.5 min. or less Time constant
(at 0.15 m/s wind velocity)
Humidity 40 sec. or less
For temperature
sensing
Rated operating condition: 0 C to 50 C, 0 %RH to 100 %RH (non-condensing)
Limit operating condition: -10 C to 60 C, 0 %RH to 100 %RH (non-condensing)
Transport/storage condition: -20 C to 70 C, 5 %RH to 95 %RH (non-condensing)
Environmental conditions
For humidity
sensing
Rated operating condition: 15 C to 35 C, 20 %RH to 80 %RH (non-condensing)
Limit operating condition: -10 C to 60 C, 0 %RH to 100 %RH (non-condensing)
Transport/storage condition: -20 C to 70 C, 5 %RH to 95 %RH (non-condensing)
Power supply 24 V DC 10 %
Power consumption 550 mW per 4-20 mA output point
Withstand voltage 1 mA or less leakage current at 500 V AC for 1 min.
Insulation resistance 500 V DC, 20 M or higher
Installation With the mounting kit (sold separately).
Connection Lead wire (0.75 mm
2
300 mm long) connection
Materials / color Cover: PC resin / Pale gray
Base: Modified PPE resin / Pale gray
Weight Approx. 110 g
Accessory 4 main unit mounting screws (M3 16)
CE Marking Conformity
Models TY7043D, HY7043D and HTY7043D comply with the following Electromagnetic Compatibility (EMC).
EMC: EN61326-1 Class B, Table 1 (For use in a basic electromagnetic environment)
(CISPR11: 2003, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-11)
