Aztech 500Mbps HomePlug AV

User Manual
Page 8 of 44
Label
Status
Description/ Function
A
Filtered AC Pass-Through
Built in AC Pass-through with Powerline Noise Filtering.
Frequency band 2-30Mhz with filtering characteristics of
-25 to -45dB. It prevents noise-generating appliances
from affecting your HomePlugAV's performance.
Only a *BS1363 plug can be plugged into socket outlet.
B
Power
Blinking
slowly
When LED is blinking slowly in Green color HomePlug
AV is on a Power Saving status.
Off
No power.
On
 After Simple Connect is pressed for two
seconds, this LED will blink to confirm the
button press.
 When Simple Connect is pressed for 10
seconds, this LED will blink to confirm the
Private Network Name reset.
C
Powerline Activity
Off
Device is not connected to a HomePlug AV network.
On
 This LED remains on when the device is part of
a HomePlug AV network.
 The LED colors represents the connection rate
within the HomePlug AV network whether it is
good (red), better (amber), or best (green).
 The LED flashes to indicate network activity.
D
Ethernet Activity
Off
An Ethernet device is not connected.
On
 An Ethernet device is connected.
 The LED flashes to indicate Ethernet activity.
E
Simple Connect Button
Press to create or join a HomePlug AV network. It can
also be used to reset the Private Network Name to a
random key.
F
Ethernet Port
Accepts either cross or straight Ethernet cable.
G
Reset Button
Press for 2 seconds to reset to the factory default
settings. When you reset to the factory default, all your
configuration changes will be removed.
