Backyard Discovery 100QT - Assembly Instructions; Step 1: Cooler Panel Assembly

Ǣǻrƻ
ˠ
ˣ˟ˠ  ʹɮˣʺ
Dŷĵǻ˚ˠˀˡ˃
ˣ˟˟ ʹɮˣʺ
ɟǢËrNJ˚˧ɮˠˤ
ˢ˨˨ ʹɮˣʺ
ŗȕǻDNJNJrĵ˚˦ˀ˧
˦˟˥ ʹɮˣʺ
ˢ˚ǢÝ^r^˚˨˟DNJNħrǻ˚Dĵħ
Nƻˠ ʹɮˠʺ
NŷŷĵrNJƻŗrĵ
COOLER PANEL - W2A03102
1 1/8"x16 5/8"x30 3/16" (28x423x766)
CP1
(x1)
BOLT WH BLK
1/4x1/2
(x4)
H100401
3-SIDED-90° BRACKET - BLK
(x4)
A4M00706
WASHER LOCK EXT BLK
8x15
(x4)
H100400
NUT BARREL WH BLK
1/4x7/8
(x4)
H100399
14
