Backyard Discovery 1605022D - Page 16

FLOOR BOARD - W4L06918
5/8"x3 3/8"x45 1/8" (16x86x1145)
(10)
M6
WALL RAIL - W4L06919
5/8"x3 3/8"x41 1/2" (16x86x1054)
(2)
M7
WALL RAIL - W4L06920
5/8"x3 3/8"x42 1/8" (16x86x1070)
(2)
M8
WALL RAIL - W4L06941
5/8"x3 3/8"x43 1/4" (16x86x1097)
(1)
M9
WALL RAIL - W4L06942
5/8"x3 3/8"x43 1/4" (16x86x1097)
(1)
M10
ARCHED WALL RAIL - W4L06943
5/8"x3 3/8"x43 1/4" (16x86x1097)
(1)
M11
Owner's Manual
Parts Identification
Wood Components (Not to Scale)
GROUND BOARD - W4L13848
5/8"x5 1/4"x80 3/8" (16x134x2043)
(1)
K1
GROUND BOARD - W4L06894
5/8"x5 1/4"x43 1/4" (16x134x1097)
(4)
K2
GROUND BOARD - W4L06896
5/8"x5 1/4"x42 1/8" (16x134x1070)
(2)
K3
GROUND BOARD - W4L13847
5/8"x5 1/4"x61 1/2" (16x134x1564)
(1)
K4
SERVING SHELF - W4L06902
5/8"x5 1/4"x40 7/8" (16x134x1038)
(1)
K5
GROUND BOARD - W4L13852
5/8"x5 1/4"x44 1/2" (16x134x1129)
(1)
K6
SAFETY BOARD - W4L06895
5/8"x3 3/8"x40 7/8" (16x86x1038)
(1)
M1
FLOOR RAIL - W4L06897
5/8"x3 3/8"x43 1/4" (16x86x1097)
(1)
M2
FLOOR RAIL - W4L06914
5/8"x3 3/8"x43 1/4" (16x86x1097)
(1)
M5
LADDER RUNG - W4L06912
5/8"x3 3/8"x20 1/4" (16x86x515)
(1)
M3
LADDER RUNG - W4L06913
5/8"x3 3/8"x20 1/4" (16x86x515)
(6)
M4
