Backyard Discovery 1605022D - Page 22

SWING BEAM
STEP 1
SWING BEAM EXTENDED - W4L06961
2"x5 1/4"x89 1/2" (50x134x2274)
SB74
(1)
SWING BEAM
EXT. BRACKET
BLUE - LEFT
(1)
A4M00511
SWING BEAM
EXT BRACKET
BLUE - RIGHT
(1)
A4M00512
L BRACKET
66x66x127 BLUE
(2)
A100153
105 (x2)
WASHER - 8x27
110 (x2)
NUT - 5/16"
105 (x2)
WASHER - 8x27
047 (x2)
BOLT - 2 3/4"
005 (x3)
NUT BARREL - 7/8"
011 (x3)
BOLT - 1 3/4"
SB74 (x1)
SWING BEAM EXTENDED
511 (x1)
SWING BEAM EXT. BRACKET BLUE - LEFT
512 (x1)
SWING BEAM EXT BRACKET BLUE - RIGHT
153 (x2)
L BRACKET 66x66x127 BLUE
BOLT WH
5/16x1 3/4
(3)
H100011
NUT BARREL WH
5/16x7/8
(3)
H100005
BOLT HEX
5/16x2 3/4
(2)
H100047
NUT LOCK
5/16
(2)
H100110
WASHER FLAT
8x27
(4)
H100105
22
