Backyard Discovery 1605022D - Page 24

STEP 3
SWING BEAM
031 (x1)
WASHER - 12x19
006 (x1)
NUT BARREL - 1 1/2"
005 (x2)
NUT BARREL - 7/8"
030 (x1)
WASHER - 8x19
014 (x1)
BOLT - 2 1/2"
011 (x2)
BOLT - 1 3/4"
WASHER
LOCK EXT
8x19
(1)
H100030
WASHER
LOCK EXT
12x19
(1)
H100031
NUT BARREL
WH
5/16x7/8
(2)
H100005
NUT BARREL
WH
5/16x1 1/2
(1)
H100006
BOLT WH
5/16x2 1/2
(1)
H100014
BOLT WH
5/16x1 3/4
(2)
H100011
A-FRAME ASSEMBLY
BEAM
ASSEMBLY
24
