Backyard Discovery 1605022D - Page 28

MONKEY BAR
STEP 3
BOLT WH
5/16x1-1/2
(2)
H100010
127 (x1)
HAND GRIP LIME PLASTIC
074 (x2)
T-NUT - 5/16"
010 (x2)
BOLT - 1 1/2"
E5 (x1)
MONKEY BAR UPRIGHT
MONKEY BAR UPRIGHT - W4L13840
1 3/8"x3 3/8"x70 3/8" (36x86x1786)
E5
(1)
HAND GRIP LIME
PLASTIC
(1)
A6P00127
LAG SCREW
WH
1/4x1 1/2
(2)
H100145
T-NUT
5/16
(2)
H100074
WASHER
LOCK EXT
6x15
(2)
H100138
138 (x2)
WASHER - 6x15
145 (x2)
LAG SCREW - 1 1/2"
NOTE HOLES GO OUTWARD
28
