Backyard Discovery 1605022D - Page 29

MONKEY BAR
STEP 4
MONKEY BAR UPRIGHT - W4L13840
1 3/8"x3 3/8"x70 3/8" (36x86x1786)
E5
(1)
HAND GRIP LIME
PLASTIC
(1)
A6P00127
BOLT WH
5/16x1-1/2
(2)
H100010
LAG SCREW
WH
1/4x1 1/2
(2)
H100145
T-NUT
5/16
(2)
H100074
010 (x2)
BOLT - 1 1/2"
074 (x2)
T-NUT - 5/16"
138 (x2)
WASHER - 6x15
145 (x2)
LAG SCREW - 1 1/2"
127 (x1)
HAND GRIP LIME PLASTIC
E5 (x1)
MONKEY BAR UPRIGHT
NOTE HOLES GO OUTWARD
WASHER
LOCK EXT
6x15
(2)
H100138
29
