Backyard Discovery 1605022D - Page 32

BENCH ASSEMBLY
STEP 1
BENCH GROUND BOARD - W4L06967
1"x3 3/8"x18 1/8" (24x86x460)
H7
(2)
L BRACKET
BLUE 32x51
(2)
A4M00646
NUT BARREL WH
5/16x7/8
(2)
H100005
H7 (x2)
BENCH GROUND BOARD
646 (x2)
L BRACKET BLUE 32x51
WASHER
LOCK EXT
12x19
(2)
H100031
BOLT WH
5/16x1/2
(2)
H100115
115 (x2)
BOLT - 1/2"
031 (x2)
WASHER - 12x19
005 (x2)
NUT BARREL - 7/8"
32
