BENCH ASSEMBLY
STEP 2
SCREW PFH
8x1 3/4
(8)
H100089
BENCH UPRIGHT - W4L06968
1"x3 3/8"x11 3/4" (24x86x300)
H8
(2)
H8
(x8)
BENCH UPRIGHT
089
(x8)
SCREW - 1 3/4"
33
