BENCH ASSEMBLY
STEP 3
BENCH SEAT SUPPORT - W4L06969
1"x3 3/8"x6 1/2" (24x86x166)
H9
(2)
SCREW PFH
8x1 3/4
(8)
H100089
089
(x8)
SCREW - 1 3/4"
H9
(x2)
BENCH SEAT SUPPORT
34
