Backyard Discovery 1605022D - Page 56

BOLT WH
5/16x1-1/2
(1)
H100010
WALL BOARD - W4L06947
1"x2 3/8"x25" (24x60x634)
(1)
J8
L BRACKET
2.5x38x55x55
(1)
A4M01048
NOTE CENTER HOLES
ON J8 BOARD LOCATED
CLOSER TO THE DECK.
FORT ASSEMBLY
STEP 19
BOLT WH
5/16x1/2
(1)
H100115
LAG SCREW WH
1/4x1 1/2
(1)
H100145
NUT BARREL
WH
5/16x7/8
(1)
H100005
WASHER
LOCK EXT
8x19
(1)
H100030 WASHER
LOCK EXT
12x19
(1)
H100031
T-NUT
5/16
(1)
H100074
074 (x1)
T-NUT - 5/16"
J8 (x1)
WALL BOARD
030 (x1)
WASHER - 8x19
010 (x1)
BOLT - 1 1/2"
031 (x1)
WASHER - 12x19
005 (x1)
NUT BARREL - 7/8"
145 (x1)
LAG SCREW - 1 1/2"
115 (x1)
BOLT - 1/2"
048 (x1)
L BRACKET 2.5x38x55x55
56
