Backyard Discovery 1605022D - Page 55

LAG SCREW WH
5/16x1 1/2
(4)
H100026
T-NUT
5/16
(2)
H100074
WALL RAIL - W4L06942
5/8"x3 3/8"x43 1/4" (16x86x1097)
(1)
M10
ARCHED WALL RAIL - W4L06943
5/8"x3 3/8"x43 1/4" (16x86x1097)
(1)
M11
FORT ASSEMBLY
STEP 18
WASHER
LOCK EXT
8x19
(4)
H100030
026 (x4)
LAG SCREW - 1 1/2"
030 (x4)
WASHER - 8x19
074 (x2)
T-NUT - 5/16"
INSTALL BEFORE
MOUNTING BOARD
M11 (x1)
ARCHED WALL RAIL
M10 (x1)
WALL RAIL
55
