SCREW PFH
8x1 1/8
(18)
H100088
PICKET - W4L06944
5/8"x1 3/8"x18 1/4" (16x34x465)
(9)
O2
FORT ASSEMBLY
STEP 22
CENTER O2 BOARDS IN OPENING, APPROXIMATELY
1 7/8" - 46mm DOWN FROM M10 BOARD.
2 7/8" - 72mm SPACING BETWEEN PICKETS.
O2 (x9)
PICKET
088 (x18)
SCREW - 1 1/8"
M10
WALL RAIL
