Backyard Discovery 1605022D - Page 75

FINAL STEP
DOUBLE CHECK EVERY BOLT, SCREW AND NUT FOR TIGHTNESS. MAKE SURE EVERY BOARD IS SECURE
AND MAKE SURE THE PLAY SET IS LEVEL.
ENJOY YOUR NEW PLAY SET!
NOTE:
FAILURE TO USE GROUND STAKES CAN VOID
WARRANTY & CAUSE INJURY!
BOLT WH
5/16x1 1/4
(2)
H100009
STEP 38
AUGER GROUND STAKE
(8)
A100178
ANCHORING
009 (x2)
BOLT - 1 1/4"
031 (x2)
WASHER - 12x19
005 (x2)
NUT BARREL - 7/8"
004 (x4)
NUT BARREL - 5/8"
031 (x4)
WASHER - 12x19
222 (x4)
BOLT - 3/4"
222 (x2)
BOLT - 3/4"
031 (x2)
WASHER - 12x19
004 (x2)
NUT BARREL - 5/8"
SCREW AUGER INTO GROUND AT LOCATIONS SHOWN. USING AUGER AS
A TEMPLATE DRILL 3/8" - (10mm) HOLES THRU BOARD, & ATTACH USING
SUPPLIED HARDWARE.
NUT BARREL
WH
5/16 x 5/8
(6)
H100004
WASHER
LOCK EXT
12x19
(8)
H100031
BOLT WH
5/16x3/4
(6)
H100222
NUT BARREL
WH
5/16x7/8
(2)
H100005
