Backyard Discovery 1905016B - Page 22

SWING BEAM ASSEMBLY
STEP 2
BOLT WH 5/16x1/2
(2 PLCS)
WASHER LOCK EXT 8x19
(2 PLCS)
WASHER LOCK EXT 12x19
(2 PLCS)
NUT BARREL WH 5/16x7/8
(2 PLCS)
Q1
Q1
Q1 - SWING BEAM GROUND BOARD - W4L07242
1"x4 3/8
"x45 5/8" (24x112x1160)
(2)
WASHER LOCK EXT
12x19
H10
0031
(2)
WASHER LOCK EXT
8x19
H100030
(2)
NUT BARREL WH
5/16x7/8
H100005
(2)
BOLT WH 5/16x1/2
H100115
(2)
22
