Backyard Discovery 1905016B - Page 31

SPEEDY SLIDE ASSEMBLY
STEP 4
● ONCE THE SLIDE BED, AND SUPPORT BOARDS ARE COMPLETELY IN THE CAVITY AND SUPPORT POCKET,
SECURE USING 2-1/2" SCREWS AT EACH OF THE PILOT HOLE LOCATIONS AS SHOWN.
● REPEAT PROCESS FOR OPPOSITE SLIDE RAIL.
SCREW PFH
8x2 1/2
(
24)
SCREW PFH 8x2 1/2
(12 PLCS)
SCREW PFH 8x2 1/2
(12 PLCS)
31
