Backyard Discovery 1905016B - Page 40

STEP 9
M3 - GROUND BOARD - W4L04794
5/8"x3 3/8"x23 1/4" (16x86x590)
(2)
SCREW PFH
8x1-1/2"
(8)
M3
M3
SCREW PFH 8x1-1/2"
(8 PLCS)
NOTE:
ALIGN PILOT HOLES IN M3 GROUND BOARDS
WITH PILOT HOLES IN UPRIGHTS. INSTALL AS
SHOWN.
