Backyard Discovery 1905016B - Page 39

STEP 8
BOLT WH
5/16x4-1/4
(8)
T-NUT 5/16
(6)
WASHER
LOCK EXT
8x19
(10)
INSERT T-NUTS INTO 'H3'
BOARD BEFORE ASSEMBLY.
RIGHT SIDE GROUND
BOARD ASSEMBLY
(1) RIGHT SIDE GROUND BOARD ASSEMBLY
BOLT WH
5/16x1/2
(2)
NUT BARREL
WH 5/16x7/8
(2)
H3 - FLOOR RAIL - W4L12104
1"x3 3/8"x46" (24x86x1168)
(1)
H3
T-NUT 5/16
(6 PLCS)
WASHER LOCK EXT 8x19
(4 PLCS)
BOLT WH 5/16x4-1/4
(4 PLCS)
WASHER LOCK EXT 8x19
(4 PLCS)
BOLT WH 5/16x4-1/4
(4 PLCS)
NUT BARREL WH 5/16x7/8
(2 PLCS)
WASHER LOCK EXT 8x19
(2 PLCS)
BOLT WH 5/16x1/2
(2 PLCS)
BACK
RIGHT
UPRIGHT
ASSEMBLY
FRONT
RIGHT
UPRIGHT
ASSEMBLY
NOTE HOLE LOCATION
NOTE HOLE LOCATION
(1) BACK RIGHT UPRIGHT ASSEMBLY
(1) FRONT RIGHT UPRIGHT ASSEMBLY
H3
39
