STEP 7
RIGHT SIDE GROUND BOARD ASSEMBLY
WASHER
LOCK EXT
8x19
(2)
H1 - UNIVERSAL GROUND BOARD - W4L06276
1"x3 3/8"x42" (24x86x1066)
(2)
T-NUT 5/16
(2)
BOLT WH
5/16x1
(2)
H1
H1
BOLT WH 5/16x1
(2 PLCS)
WASHER LOCK EXT 8x19
(2 PLCS)
T-NUT 5/16
(2 PLCS)
