Backyard Discovery 1905016B - Page 45

BOLT WH
5/16x4
(8)
LAG SCREW
WH 5/16x2
(2)
WASHER
LOCK EXT
8x19
(14)
STEP 14
L1 - TOP RAIL - W4L15012
5/8" x 4 3/8" x 44 7/8" (16 x 112 x 1140)
(2)
H4 - ANGLE BRACE - W4L06561
1"x3 3/8"x14" (24x86x355)
(4)
BOLT WH
5/16x1
(4)
LAG SCREW
WH 1/4x2
(4)
NUT BARREL
WH 5/16x7/8
(4)
WASHER
LOCK EXT
6x15
(4)
WASHER
LOCK EXT
12x19
(4)
WASHER LOCK EXT 8x19
(2 PLCS)
WASHER LOCK EXT 12x19
(4 PLCS)
WASHER LOCK EXT 8x19
(8 PLCS)
BOLT WH 5/16x4
(8 PLCS)
L1
L1
H44 PLCS
LAG SCREW WH 5/16x2
(2 PLCS)
WASHER LOCK EXT 6x15
(4 PLCS)
LAG SCREW WH 1/4x2
(4 PLCS)
BOLT WH 5/16x1
(4 PLCS)
WASHER LOCK EXT 8x19
(4 PLCS)
NUT BARREL WH 5/16x7/8
(4 PLCS)
L1
H4
BOLT WH 1/4x1/2
(4 PLCS)
NUT BARREL WH 1/4x5/8
(4 PLCS)
WASHER LOCK EXT 8x15
(4 PLCS)
90° L-BRACKET - BLK
(4 PLCS)
BOLT WH
1/4x1/2
(4)
NUT BARREL
WH 1/4x5/8
(4)
WASHER
LOCK EXT
8x15
(4)
- 90° L-BRACKET - BLK - A4M00555
(4)
45
