SCREW PWH
8x5/8
(9)
- TARP .4x580x1736 - A6P00328
(1)
STEP 16
TARP .4x580x1736
(1 PLC)
SCREW PWH 8x5/8
(3 PLC)
SCREW PWH 8x5/8
(6 PLCS)
(3 LEFT, 3 RIGHT)
ADJUST OVERLAP SO
TARP IS TIGHT
1.60 SPACING
47
