Backyard Discovery 2104617 - Page 17

Ǣǻrƻˢ
BOLT WH BLK
5/16x4 3/4
(x8)
H100480
NUT BARREL WH BLK
5/16x1-1/2
(x8)
H100193
BOLT WH BLK
5/16x1 1/4
(x4)
H100459
WASHER LOCK EXT BLK
12x19
(x12)
H100199
LAG SCREW WH BLK
5/16x1 1/2
(x4)
H100471
NUT BARREL WH BLK
5/16x5/8
(x4)
H100469
WASHER LOCK EXT BLK
8x19
(x8)
H100198
RAIL - W4L14101
1"x4 1/2"x52" (24x112x1322)
Q1
(x1)
RAIL - W4L14317
1 1/2"x3 1/2"x42 1/2" (36x86x1076)
E2
(x1)
L BRACKET 51x32x82x3.175
(x2)
A4M00855
NOTE HOLES FACE
UPWARDS.
ˣˤ˨ ʹɮˣʺ
Dŷĵǻ˚ˠˠˀˣ˃
ˠ˨˨ ʹɮˣʺ
ɟǢËrNJ˚ˠˡɮˠ˨
ˣ˥˨ ʹɮˣʺ
ŗȕǻDNJNJrĵ˚ˤˀ˧
ˠ˨ˢ ʹɮ˧ʺ
ŗȕǻDNJNJrĵ˚ˠˠˀˡ˃
ˠ˨˨ ʹɮ˧ʺ
ɟǢËrNJ˚ˠˡɮˠ˨
ˣ˧˟ ʹɮ˧ʺ
Dŷĵǻ˚ˣˢˀˣ˃
NOTE HOLE LOCATIONS
ON BOTH POST FACE
SAME DIRECTION.
ƻˡ
ƻŷǢǻ
ƻˠ
ƻŷǢǻ
ˠ˨˧ ʹɮ˧ʺ
ɟǢËrNJ˚˧ɮˠ˨
˧ˤˤ ʹɮˡʺ
ĵDNJNħrǻˤˠɮˢˡɮ˧ˡɮˢʳˠ˦ˤ
ˣ˦ˠ ʹɮˣʺ
ĵµǢNNJrɟ˚ˠˠˀˡ˃
HAND TIGHTEN ONLY. DO NOT
TIGHTEN THIS CONNECTION
UNTIL TABLE IS INSTALLED.
rˡ ʹɮˠʺ
NJÝĵ
džˠ ʹɮˠʺ
NJÝĵ
17
