Backyard Discovery 2105324 - Page 12

Owner's Manual
ɟŸŸ_NŸŎƼŸŘsŘǼǣʹŗŸǼǼŸǢOĶsʺ
ƻNjǼǣÝ_sŘǼÞ¯ÞOǼÞŸŘ
RIDGE CAP STIFFENER - W4L15003
1"x2 3/8"x89 1/2" (24x60x2273)
J10
(x2)
RIDGE CAP STIFFENER - W4L15002
1"x2 3/8"x77 5/8" (24x60x1973)
J09
(x2)
GP1
(x2)
GABLE PANEL - W2A02871
2 13/16"x5 1/4"x80 3/16" (72x134x2037)
GP2
(x2)
GABLE PANEL - W2A02872
2 13/16"x5 1/4"x80 3/16" (72x134x2037)
P01
(x2)
POST - W2A02873
6"x6"x89 1/2" (152x152x2274)
P02
(x2)
POST - W2A02874
6"x6"x89 1/2" (152x152x2274)
GT1
(x4)
GABLE TRUSS - W2A02875
1 7/16"x33 5/8"x64 9/16" (36x854x1640)
CA01
(x1)
CORBEL - W2A02879
1 7/16"x5 3/8"x46 1/16" (36x136x110)
FASCIA - W4L15005
1"x3 3/8"x63 1/2" (24x86x1614)
H06
(x2)
FASCIA - W4L15006
1"x3 3/8"x70 1/8" (24x86x1783)
H07
(x2)
RAFTER - W4L15000
1"x3 3/8"x69 1/2" (24x86x1766)
H05
(x2)
