STEP 35
˥ˢ˟ ʹɮˠ˥ʺ
ɟǢËrNJ˚˧ɮˠ˨
ˠˡ˟ ʹɮˠ˥ʺ
ǢNNJrɟ˚ˡ˃
PRE-DRILL HOLES FOR CONCRETE ANCHORS
USING A 3/16" CONCRETE DRILL BIT.
ŗŷǻrʲ
MANUFACTURER RECOMMENDS INSTALLATION ON
CONCRETE SURFACE OR CONCRETE POST PADS. SEE BELOW.
FOR INSTALLATION ON WOOD DECK, YOU MUST ENSURE
THERE IS AMPLE STRUCTURAL SUPPORT UNDER DECK.
HARDWARE NOT INCLUDED
SCREW CONCRETE ANCHOR
1/4x2
(x16)
H100120
WASHER FLAT BLK
8x19
(x16)
H100630
52
