STEP 7:
REAR
LEFT
FRONT
RIGHT
SCREW PFH 8x1 1/4
(4 PLCS)
SCREW PFH
8x1 1/4
(4)
J1
J1
J1 - OUTER COUNTER SUPPORT - W4L05575
1"x2 3/8"x8 3/8" (24x60x213)
(2)
FLUSH
FLUSH
