STEP 23:
REAR
LEFT
FRONT
RIGHT
SCREW PFH 6x1
(4 PLCS)
SCREW PFH
6x1
(4)
5/8" UP FROM
METAL TIE
STRAP.
(1)
DP1
DP1 - DOOR PANEL - W2A01761
1 1/8"x13"x17 1/4" (27x330x438)
