Backyard Discovery 9198012 - Page 27

Phase 3
STEP 2
BOLT WH BLK
5/16x1 1/2
(x4)
H100407
T-NUT BLK
5/16
(x4)
H100379
(1)-TUBE SLIDE SUB-ASSEMBLY
(1)-SLIDE BRACE SUB-ASSEMBLY
HAMMER T-NUTS INTO PROVIDED
HOLES I
N 'E85' AND 'E86'.
NOTE:
407 (x4)
BOLT - 1 1/2"
379 (x4)
T-NUT - 5/16"
(1)-SLIDE BRACE SUB-ASSEMBLY
27
