Backyard Discovery 9198074 - Phase 1 Assembly; Step 1: Slide Entrance Assembly

Phase 1
STEP 1
SLIDE ENTRANCE LEFT
(x1)
A6P00302-2
SLIDE ENTRANCE RIGHT
(x1)
A6P00302-1
BOLT PTH WZ
1/4x3/4
(x8)
H100769
NUT LOCK WZ
1/4
(x8)
H100148
769 (x8)
BOLT - 3/4"
302-1 (x1)
SLIDE ENTRANCE RIGHT
302-2 (x1)
SLIDE ENTRANCE LEFT
TIP:
LAYING THE PARTS ON THEIR FLAT
END MAKES ASSEMBLY EASIER.
148 (x8)
NUT - 1/4"
