Backyard Discovery 9198074 - Step 2: Slide Elbow Assembly

STEP 2
Phase 1
SLIDE ELBOW
(x8)
A6P00302-4
BOLT PTH WZ
1/4x3/4
(x32)
H100769
NUT LOCK WZ
1/4
(x32)
H100148
NOTE:
REPEAT THIS STEP (3) MORE TIMES.
302-4 (x2)
SLIDE ELBOW
148 (x8)
NUT - 1/4"
769 (x8)
BOLT - 3/4"
