QTY
PART NUMBER DESCRIPTION
6 H100087 SCREW PFH 8x1-1/4"
STEP 21 - FORT ASSEMBLY
087 (x6)
SCREW - 1-1/4"
BAY WINDOW
ASSEMBLY
USING BAY WINDOW ASSEMBLY AS
A TEMPLATE, DRILL (6) 1/8" [3mm]
HOLES THRU 'M9' & 'L2'.
L2
M9
53
