Backyard Discovery Bay Pointe - Ladder Assembly; Step 1: Ladder Rung Assembly

STEP 1
LADDER ASSEMBLY
063 (x8)
BOLT - 3/4"
108 (x8)
WASHER - 8x15
072 (x8)
T-NUT - 1/4"
L4 (x4)
LADDER RUNG
BOLT PTH
1/4x3/4
(x8)
H100063
WASHER
LOCK INT
8x15
(8)
H100108
T-NUT
1/4
(x8)
H100072
040 (x4)
BLUE HC ROCK #2
BLUE HC ROCK #2
(x4)
A6P00040
LADDER RUNG - W4L13286
5/8"x4 3/8"x16 7/8" (16x112x430)
L4
(x4)
LEFT RUNG ASSEMBLY (x2)
RIGHT RUNG ASSEMBLY (x2)
TIP:
INSTAL
L THE T-NUTS FIRST
12
