Backyard Discovery Bay Pointe - Step 2: Attaching Rungs to Uprigths

STEP 2
LADDER ASSEMBLY
086 (x20)
SCREW - 1 1/2"
SCREW PFH
8x1 1/2
(x20)
H100086
F2 (x1)
UPRIGHT
F1 (x1)
UPRIGHT
L3 (x1)
LADDER RUNG
LADDER RUNG - W4L13285
5/8"x4 3/8"x16 7/8" (16x112x430)
L3
(x1)
LEFT RUNG ASSEMBLY (x2)
RIGHT RUNG ASSEMBLY (x2)
UPRIGHT - W4L13284
1 7/16"x2 3/8"x43 3/4" (36x60x1111)
F2
(x1)
UPRIGHT - W4L13283
1 7/16"x2 3/8"x43 3/4" (36x60x1111)
F1
(x1)
TIP:
ALIGN HOLES IN RUNGS
WITH HOLES IN UPRIGHTS.
NOTE HOLE LOCATION
RIGHT RUNG ASSEMBLY (x2)
LEFT RUNG ASSEMBLY (x2)
