Backyard Discovery Bay Pointe - Swing Beam Assembly

SWING BEAM
STEP 1
047 (x2)
BOLT - 2 3/4"
105 (x4)
WASHER - 8x27
110 (x2)
NUT - 5/16"
128 (x4)
SCREW - 5/8
005 (x3)
NUT BARREL - 7/8"
011 (x3)
BOLT - 1 3/4"
153 (x2)
L BRACKET 66x66x127 BLUE
512 (x1)
SWING BEAM EXT BRACKET BLUE - RIGHT
511 (x1)
SWING BEAM EXT. BRACKET BLUE - LEFT
175 (x1)
BYD ID TAG (MEDIUM) AGES 3-10
SB74 (x1)
SWING BEAM 2 POSITION
SWING BEAM 2 POSITION - W4L13291
2"x5 1/4"x68 3/4" (50x134x1745)
SB74
(1)
SWING BEAM
EXT. BRACKET
BLUE - LEFT
(1)
A4M00511
SWING BEAM
EXT BRACKET
BLUE - RIGHT
(1)
A4M00512
L BRACKET
66x66x127 BLUE
(2)
A100153
NUT LOCK
5/16
(2)
H100110
WASHER FLAT
8x27
(4)
H100105
NUT BARREL WH
5/16x7/8
(3)
H100005
BOLT WH
5/16x1 3/4
(3)
H100011
BOLT HEX
5/16x2 3/4
(2)
H100047 SCREW PWH
8x5/8
(4)
H100128
BYD ID TAG
(MEDIUM) AGES
3-10
(1)
A100175
16
