SWING BEAM
STEP 2
105
(x4)
WASHER - 8x27
110
(x4)
NUT - 5/16"
103
(x4)
WASHER - 17x30
099
(x4)
SWING HANGER - 9 1/2"
WASHER FLAT
8x27
(4)
H100105
NUT LOCK
5/16
(4)
H100110
WASHER SAFETY
17x30
(4)
H100103
SWING HANGER
5/16x9 1/2
(4)
H100099
17
