Backyard Discovery Bay Pointe - Step 3: Swing Beam Support Assembly

SWING BEAM
STEP 3
030 (x1)
WASHER - 8x19
021 (x1)
BOLT - 4 1/2"
005 (x1)
NUT BARREL - 7/8"
031 (x1)
WASHER - 12x19
074 (x2)
T-NUT - 5/16"
030 (x2)
WASHER - 8x19
013 (x2)
BOLT - 2 1/4
030 (x2)
WASHER - 8x19
027 (x2)
LAG SCREW - 2"
E77 (x1)
ANGLE BRACE
E77 (x1)
ANGLE BRACE
W71 (x1)
SWING BEAM SUPPORT
H79 (x1)
END SUPPORT
WASHER LOCK EXT
8x19
(5)
H100030
WASHER LOCK EXT
12x19
(1)
H100031
NUT BARREL WH
5/16x7/8
(1)
H100005
BOLT WH
5/16x2 1/4
(2)
H100013
BOLT WH
5/16x4 1/2
(1)
H100021
LAG SCREW WH
5/16x2
(2)
H100027
SWING BEAM SUPPORT - W4L13292
2"x3 3/8"x44 1/4" (50x86x1123)
W71
(1)
END SUPPORT - W4L13294
1"x3 1/2"x39 1/2" (24x86x1000)
H79
(1)
ANGLE BRACE - W4L13293
1 3/8"x3 3/8"x72 7/8" (36x86x1850)
E77
(2)
T-NUT
5/16
(2)
H100074
18
