FORT ASSEMBLY
STEP 20
ROPE-CHAIN B /
SEAT B
A6P00405
(2)
405
(x2)
SWING ASSEMBLY
NOTE:
WHEN HANGING YOUR SWINGS, IT IS
REQUIRED TO ONLY TRIM AROUND
THE SPECIFIC CHAIN LOOP THAT
ALLOWS THE BOTTOM OF THE SWING
SEAT, (WHEN SETTING ON IT) TO BE
NO LOWER THAN (35cm) 13-7/8 INCHES
FROM THE GROUND.
To Next Page
