Backyard Discovery Bay Pointe - Fort Assembly - Safety Grips; Step 21: Hand Grip Installation

FORT ASSEMBLY
STEP 21
314 (x2)
HAND GRIP BLUE PLASTIC
T-NUT
1/4
(2)
H100072
LAG SCREW WH
1/4x1 1/2
(2)
H100145
BOLT WH
1/4x1-1/4
(2)
H100142
WASHER LOCK
EXT
6x15
(4)
H100138
HAND GRIP
BLUE PLASTIC
(2)
A6P00314
072 (x2)
T-NUT - 1/4"
138 (x4)
WASHER - 6x15
142 (x2)
BOLT WH - 1-1/4"
145 (x2)
LAG SCREW - 1 1/2"
40
