FORT ASSEMBLY
STEP 24
SAFETY RAIL - W4L13299
1"x2 3/8"x36 5/8" (24x60x930)
J3
(1)
SCREW PFH
8x2
(4)
H100111
111
(x4)
SCREW - 2"
J3
(x1)
43
