PLAYHOUSE
ASSEMBLY
STEP 8
RP2
(x1)
RP2
(x1)
SCREW PFH BLK
8x1 1/2
(x8)
H100200
200
(x8)
SCREW - 1 1/2"
RP2
(x2)
UPPER ROOF PANEL - W2A03167
1 3/8"x12 3/4"x44 7/8" (35x324x1140)
54
