FINAL ASSEMBLY
STEP 1
378
(x2)
BOLT - 1 3/4"
198
(x2)
WASHER - 8x19
WASHER LOCK EXT BLK
8x19
(x2)
H100198
BOLT WH BLK
5/16x1 3/4
(x2)
H100378
LADDER SUBASSEMBLY
(x1)
72
