PLAYHOUSE
ASSEMBLY
STEP 12
90° L-BRACKET - BLK
(x8)
A4M00555
ALIGN BRACKETS WITH
PILOT HOLES.
EDGES FLUSH IN
DOOR OPENINGS.
SCREW PWH BLK
8x5/8
(x8)
H100202
202
(x8)
SCREW - 5/8"
555
(x8)
90° L-BRACKET - BLK
58
