LADDER ASSEMBLY
STEP 2
SCREW PFH
8x2
(x8)
H100111
RIGHT UPRIGHT - W4L13776
1 3/8"x3 3/8"x50 3/4" (36x86x1290)
E75
(x1)
E75
(x1)
RIGHT UPRIGHT
111
(x8)
SCREW - 2"
18
