Backyard Discovery GRAYSON PEAK - Page 21

SWING BEAM
STEP 1
SWING BEAM 2 POSITION - W4L13780
2"x5 1/4"x68 3/4" (50x134x1745)
SB74
(x1) SWING BEAM
EXTENSION
BRACKET-LEFT
(x1)
A100325
SWING BEAM
EXTENSION
BRACKET-RIGHT
(x1)
A100326
L BRACKET
66x66x127
(x2)
A100140
NUT LOCK
5/16
(x2)
H100110
WASHER FLAT
8x27
(x4)
H100105
NUT BARREL WH
5/16x7/8
(x3)
H100005
BOLT WH
5/16x1 3/4
(x3)
H100011
BOLT HEX
5/16x2 3/4
(x2)
H100047
047 (x2)
BOLT - 2 3/4"
105 (x4)
WASHER - 8x27
110 (x2)
NUT - 5/16"
005 (x3)
NUT BARREL - 7/8"
326 (x1)
SWING BEAM EXTENSION BRACKET-RIGHT
325 (x1)
SWING BEAM EXTENSION BRACKET-LEFT
140 (x2)
L BRACKET 66x66x127
SB74 (x1)
SWING BEAM 2 POSITION
011 (x3)
BOLT - 1 3/4"
LEAVE 011 BOLTS HAND
TIGHT AT THIS TIME
21
