STEP 4 - ROCK WALL
TIP:
INSTALL T-NUTS IN WOOD FIRST
QTY
PART NUMBER DESCRIPTION
2 H100074 T-NUT 5/16
4
H100111
SCREW PFH 8x2"
ATTACHMENT BOARD - W4L16045
1"x3 3/8"x27 7/8" (24x86x707)
H10
(x1)
074 (x2)
T-NUT - 5/16"
H10 (x1)
111 (x4)
SCREW - 2"
H10
T-NUTS TO THE INSIDE OF
BOARD WHEN INSTALLED
SIDE VIEW
T-NUT
