Backyard Discovery HILLCREST - Page 3

RIGHT FRONT TOWER LEG - W4L15999
1 3/8"x3 3/8"x89 1/2" (36x86x2274)
E01
(x1)
DECK BRACE - W4L16002
1 3/8"x3 3/8"x15 1/2" (36x86x394)
E04
(x8)
Owner's Manual - Parts Identification
Wood Components (Not to Scale)
SWING BEAM - W4L15998
3 3/8"x5 1/4"x89 1/2" (86x134x2274)
A50
(x1)
CENTER FRONT TOWER LEG - W4L16000
1 3/8"x3 3/8"x89 1/2" (36x86x2274)
E02
(x1)
LEFT FRONT TOWER LEG - W4L16001
1 3/8"x3 3/8"x89 1/2" (36x86x2274)
E03
(x1)
END SUPPORT - W4L16003
1 3/8"x3 3/8"x44 1/8" (36x86x1120)
E50
(x1)
CENTER REAR TOWER LEG - W4L16005
1 3/8"x3 3/8"x89 1/2" (36x86x2274)
E06
(x1)
LEFT REAR TOWER LEG - W4L16006
1 3/8"x3 3/8"x89 1/2" (36x86x2274)
E07
(x1)
LEFT RAIL - W4L16007
1 3/8"x3 3/8"x64 1/2" (36x86x1640)
E72
(x1)
RIGHT RAIL - W4L16008
1 3/8"x3 3/8"x64 1/2" (36x86x1640)
E73
(x1)
E05
(x1)
RIGHT REAR TOWER LEG - W2A03282
1 3/8"x3 3/8"x89 1/2" (36x86x2274)
ANGLE BRACE - W4L16004
1 7/16"x3 3/8"x87 3/16" (36x86x2214)
E51
(x2)
LEFT UPRIGHT - W4L16028
1 3/8"x3 3/8"x50 3/4" (36x86x1290)
E74
(x1)
RIGHT UPRIGHT - W4L16029
1 3/8"x3 3/8"x50 3/4" (36x86x1290)
E75
(x1)
