Backyard Discovery HILLCREST - Fort Assembly: Upper Level and Roof; Step 12: Ladder Attachment to Fort

STEP 12 - FORT ASSEMBLY
LADDER ASSEMBLY
011 (x2)
BOLT - 1 3/4"
030 (x2)
WASHER - 8x19
074 (x2)
T-NUT - 5/16"
LADDER ASSEMBLY
TIP:
INSTALL T-NUTS IN WOOD FIRST
QTY
PART NUMBER
DESCRIPTION
2
H100011
BOLT WH 5/16x1 3/4
2 H100030 WASHER LOCK EXT 8x19
2
H100074
T-NUT 5/16
41
